Electric Winch(DC V12) is the most common winch, driven by vehicle’s own power system. It works in such a way that converting automobile engines power into electricity power to drive the motors and drag noose. It enlarges the output power by the inside planetary reducer to achieve deceleration & torsion enhancement and pull cargo.
This type is widely used in Europe.CE approved.Best Choice for ATV UTV and small jeeps.
Three stage planetary gear,stable ,strong,low noise.Perfect Choice.
| Detail Information | |
| Rated Line Pull: | 2000LB(907kg) double-line |
| Motor: | 1.2hp/0.9kw 12V, Permanent Magnet Motor |
| Gear Train: | 3-stage planetary |
| Gear Reduction Ratio: | 153:1 |
| Clutch: | pull and push |
| Cable | 4mm x 13m |
| Drum Size: | φ32mm×72mm |
| Overall Dimensions: | (L×W×H)(280×105×105mm) |
| Gross Weight: | 5.5kg |
| Duty Cycle: | Intermittently |
| Fairlead: | not include |
| Package: | 1pc/box,(315×155×180mm) |
| Mounting Bolt Pattern: | 3.15″(80mm) |
